Features:
• Ideal for manual operation due to its light weight and ergonomic design
• Processing range: 0.1-50mL
• 316L stainless steel shafts are fully autoclavable and inert for highly corrosive solutions
• All shafts are interchangeable for easy dismantling and cleaning.
• 6 modes of motor speed from 8,000 to 30,000 rpm
| Specifications |
D-160 |
| Power Supply |
110-120V/60Hz
220-240V / 50-60 Hz
|
| Motor Type Universal motor |
160 W
AC carbon brush motor
|
| Speed Range |
8000-30000rpm |
| Max. Circum. Speed |
6.3-14m/sec |
| Speed Control Dial knob |
6 stage |
| Working Volume [ H 2 O] |
0.1-50mL (Dispersing shaft
DS-160/5)
|
|
1-250mL (Dispersing shaft
DS-160/10)
|
| Max. Viscosity |
5,000mPas |
| Material of Dispersing Shaft |
SS 316L stainless steel, PTFE |
| Weight |
0.6 kg |
| Dimension [L x W x H] |
46mm x 55mm x 230mm |
| Noise |
72 dB(A) |
| Operating Environment |
0-40 ?,85% rel. humidity |
| Protection Class |
IP20 |
